Sharding an Existing Payment Gateway Transaction Table: A Complete Guide

In payment gateway systems, the transaction table often grows rapidly, leading to performance bottlenecks. One effective way to scale a transactional database is sharding — splitting the database into smaller, more manageable pieces based on a shard key. In this guide we will walk through the process of sharding an existing transaction table in PostgreSQL, explaining key considerations, risks, and two popular sharding approaches: row-based and table-based.

Key Considerations and Risks

Before diving into the implementation of sharding, it’s important to understand the key considerations and risks associated with this approach:

Considerations:

• Sharding Key: The selection of a shard key is crucial. A good shard key ensures even distribution of data, while also aligning with the most frequent query patterns. For payment transactions, transaction_date or customer_id can be used.
• Database Complexity: Sharding increases the complexity of your database management. You’ll need to manage multiple shards, ensure data consistency across shards, and optimize cross-shard queries.
• Data Migration: Migrating existing data to shards can be resource-intensive, especially when you have a large amount of data in the original transactions table.
• Maintenance Overhead: Ongoing maintenance, such as schema updates, backup, and scaling the database, becomes more complex with sharded systems.

Risks:

• Cross-Shard Queries: Queries that need to aggregate data across multiple shards can become slower and more complicated.
• Data Imbalance: If the shard key does not evenly distribute the data, some shards may become overloaded, while others are underutilized.
• Application Changes: Your application logic will need to be adapted to handle sharding, such as routing queries to the correct shard based on the shard key.

What Needs to Be Done First?

Before implementing sharding, follow these initial steps:

1. Assess Current Data Volume: Evaluate the current size of the transactions table. If the table is too large, it’s a sign that sharding might be necessary.
2. Choose a Shard Key: Choose a shard key that will ensure even distribution of data. For transaction-based data, a time-based shard key (e.g., transaction_date) or customer_id might be appropriate.
3. Decide on Sharding Strategy: Decide whether to use row-based or table-based sharding. Each approach has its pros and cons, which we’ll dive into shortly.
4. Prepare for Data Migration: Plan for migrating data from the existing transactions table to the newly created shards. This process may require downtime or a strategy for migrating data incrementally.

Row-Based vs Table-Based Sharding: Which Is Best?

Row-Based Sharding

In row-based sharding, data is distributed across different schemas based on the shard key. For example, you may create a schema for each year (e.g., shard_2022, shard_2023), and each schema will have the same table structure, with the data filtered by the year.

Pros:

• Logical Isolation: Each year or time period has its own schema, making it easy to manage and isolate data.
• Easier Schema Evolution: Schema changes can be made to individual shards without affecting other shards.

Cons:

• Limited Flexibility: The database grows based on the chosen shard key, so if the volume increases drastically, you may hit limits with the number of schemas.
• Cross-Shard Queries: Queries that span multiple years (e.g., to retrieve data from different years) will require querying multiple schemas.

Table-Based Sharding

In table-based sharding, each shard is a separate table within the same schema (e.g., transactions_2022, transactions_2023). The data is split into tables based on the shard key.

Pros:

• Fine-Grained Control: You can split data across tables in the same schema or distribute the tables across different physical instances.
• Scalability: Easier to distribute the shards across multiple database instances for horizontal scaling.

Cons:

• Schema Clutter: The same schema will have many tables, potentially cluttering it.
• Cross-Table Queries: Aggregating data across multiple tables can be cumbersome.

Sharding Example 1: Row-Based Sharding

In this example, we will shard the transactions table by the year extracted from transaction_date.

Step 1: Create Shard Schemas

-- Create schemas for each year (shard)
CREATE SCHEMA IF NOT EXISTS shard_2022;
CREATE SCHEMA IF NOT EXISTS shard_2023;

Step 2: Create Identical Tables in Each Shard

-- Create the same table in each schema
CREATE TABLE shard_2022.transactions (
    transaction_id UUID PRIMARY KEY,
    customer_id INT,
    amount NUMERIC(10, 2),
    transaction_date TIMESTAMPTZ,
    status VARCHAR(50)
);

CREATE TABLE shard_2023.transactions (
    transaction_id UUID PRIMARY KEY,
    customer_id INT,
    amount NUMERIC(10, 2),
    transaction_date TIMESTAMPTZ,
    status VARCHAR(50)
);

Step 3: Migrate Data to Shards

-- Insert data into the respective shards based on the year of TransactionDate
INSERT INTO shard_2022.transactions
SELECT * FROM transactions WHERE EXTRACT(YEAR FROM transaction_date) = 2022;

INSERT INTO shard_2023.transactions
SELECT * FROM transactions WHERE EXTRACT(YEAR FROM transaction_date) = 2023;

Step 4: Querying Data

-- Query transactions for 2022
SELECT * FROM shard_2022.transactions WHERE customer_id = 101;

-- Query transactions for 2023
SELECT * FROM shard_2023.transactions WHERE customer_id = 202;

Sharding Example 2: Table-Based Sharding

In this example, we will shard the transactions table by the year, but instead of using schemas, we will create separate tables for each year in the same schema.

Step 1: Create Shard Tables

-- Create separate tables for each year in the same schema
CREATE TABLE transactions_2022 (
    transaction_id UUID PRIMARY KEY,
    customer_id INT,
    amount NUMERIC(10, 2),
    transaction_date TIMESTAMPTZ,
    status VARCHAR(50)
);

CREATE TABLE transactions_2023 (
    transaction_id UUID PRIMARY KEY,
    customer_id INT,
    amount NUMERIC(10, 2),
    transaction_date TIMESTAMPTZ,
    status VARCHAR(50)
);

Step 2: Migrate Data to Shard Tables

-- Insert data into the respective shard tables based on the year
INSERT INTO transactions_2022
SELECT * FROM transactions WHERE EXTRACT(YEAR FROM transaction_date) = 2022;

INSERT INTO transactions_2023
SELECT * FROM transactions WHERE EXTRACT(YEAR FROM transaction_date) = 2023;

Step 3: Querying Data

-- Query transactions for 2022
SELECT * FROM transactions_2022 WHERE customer_id = 101;

-- Query transactions for 2023
SELECT * FROM transactions_2023 WHERE customer_id = 202;

Summary and Comparison: Row-Based vs. Table-Based Sharding

Row-Based Sharding (Schemas)

• Logical Separation: Better isolation with separate schemas.
• Cross-Shard Queries: Requires cross-schema queries.
• Scalability: Limited by the number of schemas.
• Operational Overhead: Higher complexity in schema management.

Table-Based Sharding (Tables)

• Logical Separation: Same schema with multiple tables.
• Cross-Shard Queries: Requires union or cross-table queries.
• Scalability: Easier to distribute tables across instances.
• Operational Overhead: Simpler table management, but more tables.

Conclusion

Sharding your transactions table is an effective way to scale a payment gateway system. Whether you choose row-based or table-based sharding depends on your specific use case. Row-based sharding offers better isolation, while table-based sharding allows for greater scalability. Both approaches have their pros and cons, and choosing the right strategy requires a deep understanding of your system's requirements and future growth potential.

By following the detailed steps and examples provided, you can successfully implement sharding in your PostgreSQL database, optimizing both scalability and performance for your payment gateway system.
