The QCAT Standard: An Overview of the QR Code Specification

By mvryo


In this guide, we’ll explore the standardized format for encoding transport tickets as QR codes, designed to align with the EMV QR Code Specification for Payment Systems (EMV QRCPS), ensuring seamless integration and interoperability.

General Requirements and Features

The QR Code Standard meets the EMV QRCPS Consumer Presented Mode and includes several key features:

  • Base64 Encoded Payload: Ensures compatibility across various platforms.
  • BER-TLV Encoded Data: Facilitates efficient data transfer.
  • Mandatory EMV Data Elements: This includes:
    • Payload format indicator
    • At least one application template
    • Use of the EMV application-specific transparent template for ticket-specific data
  • Payload Limit: Maximum payload size of 512 bytes, adhering to EMVCo requirements.
  • EMVCo Processing Rules: Validation terminal QR Code readers must recognize codes that meet EMV specifications, ensuring security and reliability.

QR Ticket Format

QR Ticket Encoding

The QR Code is encoded according to ASN.1 and BER encoding rules, ensuring that data fields can be flexible in their order, presence, and quantity.

QR Code Fields

Mandatory Fields

  • Ticket Identifier
    • Tag: 1
    • Format: Unsigned Integer (32 bit)
    • Sample Value: 1250184
    • Sample TLV Value: 131388
    • Notes:
      • Must be a unique identifier
  • Ticket Creator Id
    • Tag: 2
    • Format: Unsigned Integer (16 bit)
    • Sample Value: 275
    • Sample TLV Value: 0113
  • Ticket Creation Time
    • Tag: 3
    • Format: Timestamp
    • Sample Value: 2019-09-11T19:38:30+08:00
    • Sample TLV Value: 5D78DCB6
  • Ticket Validity Period
    • Tag: 4
    • Format: Unsigned Integer (32 bit)
    • Sample Value: PT15M
    • Sample TLV Value: 0384
    • Notes:
      • Validate if expired using the following conditions
        • If Ticket Effective Time is present, Ticket Effective Time + Ticket Validity Period
        • Else, Ticket Creation Time + Ticket Validity Period

Optional Fields

  • Ticket Validity Domain
    • Tag: 5
    • Format: Unsigned Integer (16 bit)
    • Sample Value: 5
    • Sample TLV Value: 05
    • Notes:
      • Using a value of 0 means all domains
  • Transport Operator Id
    • Tag: 6
    • Format: Unsigned Integer (32 bit)
    • Sample Value: 23
    • Sample TLV Value: 17
    • Notes:
      • You can have multiple entry of this field
  • Ticket Effective Time
    • Tag: 7
    • Format: Timestamp
    • Sample Value: 2019-09-11T19:38:30+08:00
    • Sample TLV Value: 5D78DCB6
    • Notes:
      • Using a value of 0 means immediate
  • Refresh Time
    • Tag: 8
    • Format: Timestamp
    • Sample Value: 2019-09-11T19:39:00+08:00
    • Sample TLV Value: 5D78DCD4
    • Notes:
      • The QR is considered static using the following conditions
        • Using a value of 0
        • Excluding this field
  • Ticket Type
    • Tag: 9
    • Format: Unsigned Integer (16 bit)
    • Sample Value: 1
    • Sample TLV Value: 01
    • Notes:
      • Using a value of 1 means standard
  • Account Identifier
    • Tag: 10
    • Format: Unsigned Integer (16 bit)
    • Sample Value: 1234567890123456
    • Sample TLV Value: 31323334353637383930313233343536
  • Boarding Station
    • Tag: 11
    • Format: Unsigned Integer (32 bit)
    • Sample Value: 23
    • Sample TLV Value: 17
  • Destination Station
    • Tag: 12
    • Format: Unsigned Integer (32 bit)
    • Sample Value: 17
    • Sample TLV Value: 11
  • Vehicle Id
    • Tag: 13
    • Format: Unsigned Integer (32 bit)
    • Sample Value: 345
    • Sample TLV Value: 0159
  • Route Id
    • Tag: 14
    • Format: Unsigned Integer (32 bit)
    • Sample Value: 4
    • Sample TLV Value: 04
  • Seat Number
    • Tag: 15
    • Format: ASCII
    • Max Length: 5 Characters
    • Sample Value: 3D
    • Sample TLV Value: 3344
  • Seat Class
    • Tag: 16
    • Format: ASCII
    • Max Length: 5 Characters
    • Sample Value: ECO
    • Sample TLV Value: 45434F
  • Maximum Authorized Amount
    • Tag: 17
    • Format: Unsigned Integer (32 bit)
    • Sample Value: 30.00
    • Sample TLV Value: 0BB8
    • Notes:
      • This amount is in centavos
      • Using 0 as value means unlimited
  • Signature Key Identifier
    • Tag: 18
    • Format: ASCII
    • Sample Value: STAG-AFPI-V2
    • Sample TLV Value: 535441472D414650492D5632
    • Notes:
      • Used to distinguish multiple public key assigned to a single issuer
  • Terminal Identifier
    • Tag: 19
    • Format: ASCII
    • Sample Value: 1234567890
    • Sample TLV Value: 31323334353637383930
  • Funding Source Type
    • Tag: 20
    • Format: Unsigned Integer (32 bit)
    • Sample Value: 1
    • Sample TLV Value: 01
  • Funding Source Provider
    • Tag: 21
    • Format: ASCII
    • Sample Value: 1
    • Sample TLV Value: 31
  • Signature
    • Tag: 30
    • Format: Binary

Conclusion

The QR Code Standard for Transport Ticketing enhances efficiency and user experience in public transport systems. By adhering to strict guidelines, this standard ensures secure, reliable, and flexible ticketing solutions for various transport providers.

If you’d like to learn more or get involved in the QCAT ecosystem, feel free to check out my guides on QCAT specification below or check out AF Payments Inc.'s GitHub for the latest updates and contribution guidelines.

Don't forget to subscribe to my blog so you never miss out on my latest guides and content!

DISCLAIMER

The information provided in this article is for informational purposes only and does not constitute professional advice. While efforts have been made to ensure accuracy, AF Payments Inc. reserves the right to update or modify the QCAT standard and related materials at any time. Use of the QCAT standard is subject to the terms of its license agreement, and any implementation must adhere to AFPI's guidelines and licensing requirements. For the latest details and official documentation, please refer to AF Payments Inc.'s authorized channels.
