Behavioral Design Patterns for Beginners

Behavioral Design Patterns in Object-Oriented Programming (OOP) are concerned with how objects interact and communicate with each other. They define the flow of control and responsibility among different objects in a flexible way. By using these patterns, you can enhance the way your software components collaborate.

In this guide, we will explore the following behavioral design patterns:

• Chain of Responsibility
• Command
• Interpreter
• Iterator
• Mediator
• Memento
• Observer
• State
• Strategy
• Template Method
• Visitor

Each pattern is explained with a Kotlin example that can be tested using the Kotlin Playground.

Chain of Responsibility Pattern

The Chain of Responsibility pattern allows multiple objects to handle a request, passing the request along a chain until one of the objects handles it.

Example

abstract class Handler {
    var next: Handler? = null

    fun setNext(handler: Handler): Handler {
        this.next = handler
        return handler
    }

    abstract fun handleRequest(request: String)
}

class ConcreteHandlerA : Handler() {
    override fun handleRequest(request: String) {
        if (request == "A") {
            println("Handled by ConcreteHandlerA")
        } else {
            next?.handleRequest(request)
        }
    }
}

class ConcreteHandlerB : Handler() {
    override fun handleRequest(request: String) {
        if (request == "B") {
            println("Handled by ConcreteHandlerB")
        } else {
            next?.handleRequest(request)
        }
    }
}

fun main() {
    val handlerA = ConcreteHandlerA()
    val handlerB = ConcreteHandlerB()

    handlerA.setNext(handlerB)
    handlerA.handleRequest("A")  // Handled by ConcreteHandlerA
    handlerA.handleRequest("B")  // Handled by ConcreteHandlerB
    handlerA.handleRequest("C")  // Not handled
}

Command Pattern

The Command pattern turns a request into an object, allowing for parameterization of clients with different requests, queuing of requests, and logging.

Example

interface Command {
    fun execute()
}

class Light {
    fun turnOn() = println("Light turned on")
    fun turnOff() = println("Light turned off")
}

class TurnOnCommand(private val light: Light) : Command {
    override fun execute() = light.turnOn()
}

class TurnOffCommand(private val light: Light) : Command {
    override fun execute() = light.turnOff()
}

class RemoteControl {
    private val commands = mutableListOf<Command>()

    fun addCommand(command: Command) {
        commands.add(command)
    }

    fun executeCommands() {
        commands.forEach { it.execute() }
        commands.clear()
    }
}

fun main() {
    val light = Light()
    val turnOnCommand = TurnOnCommand(light)
    val turnOffCommand = TurnOffCommand(light)
    val remoteControl = RemoteControl()

    remoteControl.addCommand(turnOnCommand)
    remoteControl.addCommand(turnOffCommand)

    remoteControl.executeCommands()
}

Interpreter Pattern

The Interpreter pattern defines a representation for a language’s grammar and provides an interpreter to evaluate sentences in the language.

Example

interface Expression {
    fun interpret(context: String): Boolean
}

class TerminalExpression(private val data: String) : Expression {
    override fun interpret(context: String): Boolean {
        return context.contains(data)
    }
}

class OrExpression(private val expr1: Expression, private val expr2: Expression) : Expression {
    override fun interpret(context: String): Boolean {
        return expr1.interpret(context) || expr2.interpret(context)
    }
}

fun main() {
    val isMale = OrExpression(TerminalExpression("John"), TerminalExpression("Mike"))

    println(isMale.interpret("John is here"))  // true
    println(isMale.interpret("Sarah is here")) // false
}

Iterator Pattern

The Iterator pattern provides a way to access the elements of an aggregate object sequentially without exposing its underlying representation.

Example

class NameCollection(private val names: List<String>) {
    fun iterator(): Iterator<String> {
        return names.iterator()
    }
}

fun main() {
    val collection = NameCollection(listOf("John", "Jane", "Mike"))
    val iterator = collection.iterator()

    while (iterator.hasNext()) {
        println(iterator.next())
    }
}

Mediator Pattern

The Mediator pattern defines an object that controls how a set of objects interact, centralizing communication and reducing dependencies between them.

Example

interface Mediator {
    fun send(message: String, colleague: Colleague)
}

abstract class Colleague(protected val mediator: Mediator) {
    abstract fun receive(message: String)
}

class ConcreteColleagueA(mediator: Mediator) : Colleague(mediator) {
    fun sendMessage(message: String) {
        mediator.send(message, this)
    }

    override fun receive(message: String) {
        println("Colleague A received: $message")
    }
}

class ConcreteColleagueB(mediator: Mediator) : Colleague(mediator) {
    override fun receive(message: String) {
        println("Colleague B received: $message")
    }
}

class ConcreteMediator : Mediator {
    lateinit var colleagueA: ConcreteColleagueA
    lateinit var colleagueB: ConcreteColleagueB

    override fun send(message: String, colleague: Colleague) {
        if (colleague == colleagueA) {
            colleagueB.receive(message)
        } else {
            colleagueA.receive(message)
        }
    }
}

fun main() {
    val mediator = ConcreteMediator()
    val colleagueA = ConcreteColleagueA(mediator)
    val colleagueB = ConcreteColleagueB(mediator)

    mediator.colleagueA = colleagueA
    mediator.colleagueB = colleagueB

    colleagueA.sendMessage("Hello from A")
}

Memento Pattern

The Memento pattern captures and externalizes an object’s internal state, allowing it to be restored later without exposing its internals.

Example

class Memento(val state: String)

class Originator {
    var state: String = ""

    fun save(): Memento {
        return Memento(state)
    }

    fun restore(memento: Memento) {
        state = memento.state
    }
}

fun main() {
    val originator = Originator()
    originator.state = "State #1"

    val savedState = originator.save()
    originator.state = "State #2"
    println("Current State: ${originator.state}")

    originator.restore(savedState)
    println("Restored State: ${originator.state}")
}

Observer Pattern

The Observer pattern defines a one-to-many dependency between objects so that when one object changes state, all its dependents are notified and updated automatically.

Example

interface Observer {
    fun update(message: String)
}

class ConcreteObserver(private val name: String) : Observer {
    override fun update(message: String) {
        println("$name received: $message")
    }
}

class Subject {
    private val observers = mutableListOf<Observer>()

    fun addObserver(observer: Observer) {
        observers.add(observer)
    }

    fun notifyObservers(message: String) {
        observers.forEach { it.update(message) }
    }
}

fun main() {
    val subject = Subject()
    val observer1 = ConcreteObserver("Observer 1")
    val observer2 = ConcreteObserver("Observer 2")

    subject.addObserver(observer1)
    subject.addObserver(observer2)

    subject.notifyObservers("Update 1")
}

State Pattern

The State pattern allows an object to alter its behavior when its internal state changes. The object will appear to change its class.

Example

interface State {
    fun handle()
}

class ConcreteStateA : State {
    override fun handle() = println("State A handling request")
}

class ConcreteStateB : State {
    override fun handle() = println("State B handling request")
}

class Context(var state: State) {
    fun request() = state.handle()
}

fun main() {
    val context = Context(ConcreteStateA())

    context.request() // State A handling request
    context.state = ConcreteStateB()
    context.request() // State B handling request
}

Strategy Pattern

The Strategy pattern defines a family of algorithms, encapsulates each one, and makes them interchangeable.

Example

interface Strategy {
    fun execute(a: Int, b: Int): Int
}

class AddStrategy : Strategy {
    override fun execute(a: Int, b: Int) = a + b
}

class SubtractStrategy : Strategy {
    override fun execute(a: Int, b: Int) = a - b
}

class Context(private var strategy: Strategy) {
    fun setStrategy(strategy: Strategy) {
        this.strategy = strategy
    }

    fun executeStrategy(a: Int, b: Int): Int {
        return strategy.execute(a, b)
    }
}

fun main() {
    val context = Context(AddStrategy())
    println("Addition: ${context.executeStrategy(5, 3)}") // 8

    context.setStrategy(SubtractStrategy())
    println("Subtraction: ${context.executeStrategy(5, 3)}") // 2
}

Template Method Pattern

The Template Method pattern defines the skeleton of an algorithm, deferring some steps to subclasses without changing the overall structure.

Example

abstract class Game {
    abstract fun initialize()
    abstract fun startPlay()
    abstract fun endPlay()

    fun play() {
        initialize()
        startPlay()
        endPlay()
    }
}

class Football : Game() {
    override fun initialize() = println("Football Game Initialized")
    override fun startPlay() = println("Football Game Started")
    override fun endPlay() = println("Football Game Finished")
}

fun main() {
    val game = Football()
    game.play()
}

Visitor Pattern

The Visitor pattern allows adding new operations to objects without modifying them by letting a “visitor” object perform the operations.

Example

interface Visitable {
    fun accept(visitor: Visitor)
}

class ConcreteElementA : Visitable {
    override fun accept(visitor: Visitor) {
        visitor.visit(this)
    }
}

class ConcreteElementB : Visitable {
    override fun accept(visitor: Visitor) {
        visitor.visit(this)
    }
}

interface Visitor {
    fun visit(element: ConcreteElementA)
    fun visit(element: ConcreteElementB)
}

class ConcreteVisitor : Visitor {
    override fun visit(element: ConcreteElementA) = println("Visited Element A")
    override fun visit(element: ConcreteElementB) = println("Visited Element B")
}

fun main() {
    val elements = listOf(ConcreteElementA(), ConcreteElementB())
    val visitor = ConcreteVisitor()

    elements.forEach { it.accept(visitor) }
}

Conclusion

In this guide, we explored Behavioral Design Patterns with Kotlin examples:

1. Chain of Responsibility: Passes requests along a chain until handled.
2. Command: Encapsulates a request as an object.
3. Interpreter: Interprets a language.
4. Iterator: Provides a way to traverse collections.
5. Mediator: Centralizes communication between objects.
6. Memento: Captures and restores object state.
7. Observer: Notifies multiple objects of state changes.
8. State: Alters behavior based on an object’s state.
9. Strategy: Encapsulates algorithms and makes them interchangeable.
10. Template Method: Defines an algorithm’s skeleton with customizable steps.
11. Visitor: Adds new operations to objects without modifying them.

These patterns enhance communication between objects in a flexible way. Test these patterns in a Kotlin playground for hands-on experience.
